Description :

Details:

Standard Size(custom-made size is welcome):

1)Span Width: 3m,6m,8m,9m,10m,12m,15m,18m,20m,21m,25m,30m,40m.

2)Length: not limited,extended by 3m/unit or 5m/unit.

3)Eave height: from 2m to 10m,standard is 2.5m,3m,4m and 5m.

Frame Material:

1)Hard pressed extruded aluminium 6061/T6(15HW) with Fluorine carbon paint coating(PVDF).

2)Conector is made of zinc powder-coated steel.

3)The frame is strong,durable,light in weight,not easy to rust and distort

Fabric Material:

1)Double PVC-coated polyester textile.Any color is available.

2)850g/m2 for roof PVC,650g/m2 for sidewall PVC.

3)Waterproof and anti-leakage,Anti-UV,Anti-mildew,flame retardant to DIN4102 B1/M2

4)Temperature resistance(°C) :-40°C-70°C.

Character & Features:

1)The maximum allowed wind speed is 100km/h.

2)No pole inside,space can be 100% utilized.

3)very easy and very fast to install and dismantle.

4)Convinient to transport and store,Temporary or permanent use is available.

5)Can be fixed on all grounds with Expansion screw/Steel nail/Weight plate.

Here's a step-by-step guide on how to install a heavy-duty event tent:

Choose a Suitable Location:

Select a flat and level area large enough to accommodate the tent size and any additional space required for guy ropes, anchors, or support structures. Ensure there are no underground utilities or obstacles that could interfere with installation.

Prepare the Site:

Clear the installation area of debris, rocks, branches, or any other obstructions. If necessary, mow the grass or level the ground to create a smooth surface for the tent to rest on.

Layout the Components:

Lay out all the components of the tent, including the frame sections, fabric cover, stakes, anchors, and any additional accessories. Organize the components according to the manufacturer's instructions to facilitate assembly.

Assemble the Frame:

Begin by assembling the frame of the tent according to the manufacturer's instructions. Start with the base plates or feet and connect the frame poles, beams, and connectors in the designated sequence. Ensure that all frame components are securely fastened and aligned correctly.

Erect the Tent Structure:

Once the frame is assembled, raise it into position by lifting the frame poles or using lifting equipment if necessary. Enlist the help of a team to ensure the frame is lifted safely and evenly. Check that the frame is positioned correctly and stands upright before proceeding.

Anchor the Tent:

Secure the tent frame to the ground by anchoring it with stakes, anchors, or weights. Drive stakes through the designated holes in the base plates or feet of the frame and into the ground at a slight angle for better stability. Use ratchet straps or tensioning systems to tighten the frame and ensure it is firmly anchored.

Install the Fabric Cover:

Once the frame is anchored, install the fabric cover or canopy according to the manufacturer's instructions. Stretch the fabric over the frame and secure it in place using straps, clips, or hook-and-loop fasteners. Ensure the fabric is taut and wrinkle-free for a professional appearance.

Secure Additional Features:

Install any additional features or accessories such as sidewalls, doors, windows, flooring, lighting, and HVAC systems as needed. Follow the manufacturer's instructions to ensure proper installation and functionality.

Inspect and Test:

Once the tent is fully assembled, inspect the entire structure for any signs of damage, loose connections, or missing components. Test the stability of the tent by applying gentle pressure to the frame and checking for any movement or instability.

Secure Perimeter and Final Adjustments:

Secure the perimeter of the tent by attaching guy ropes or additional anchors to the designated anchor points around the tent. Make any final adjustments to the tensioning of the fabric cover or frame components to ensure the tent is secure and stable.

Complete Safety Checks and Sign-Off:

Conduct a final safety check to ensure that all components are properly installed and secure. Once satisfied, sign off on the installation and inform relevant personnel that the tent is ready for use.
