| Brand Name: | Tendars |
| Model Number: | Big tent |
| MOQ: | 25 square meters |
| Price: | Reconsideration |
| Packaging Details: | 1, The aluminium frame structure packed into the bubble film 2, the pvc fabric roof cover and sidewalls are packed into the PVC fabric carry bag; 3, Hardware packed into the box. |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
|
Item |
Specification |
|
Clear-span width |
3m - 50m |
|
Eave height |
2.6m /3m/4m/5m/6m or customized |
|
Ridge height |
4.3 - 8m or customized |
|
Roof pitch |
20 |
|
Longest component |
3.7-10.6m |
|
Minimum tent length |
Can be customized |
|
Roof fixing |
No limited |
|
Max.allowed wind speed |
100km/hour, 0.5kn/m³ |
|
Eave/Ridge connection |
Hot-dip Galvanized steel insert |
|
Materials |
(1) Frame structure: Hard pressed extruded aluminium 6061 /T6(15HW) which can last 15 to 25 years. |
|
(2) Fabric cover: High quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV |
|
|
resistant, tear resistant, self-cleaning ability, etc. |
|
|
(3) Connector: Strong hot-DIP galvanized steel |
|
|
Features |
(1) Allowed temperature condition: -30 degree Celsius~+70 degree Celsius |
|
(2) Wind load: Max. 80km/h (can be reinforced) |
|
|
(3) Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design) |
|
|
(4) Easy to be assembled and dismantled, movable. |
|
|
(5) No pole inside, 100% available interior space. |
|
|
Optional accessories |
(1) covers: Colourful cover, transparent cover, inflatable roof cover |
|
(2) windows: Dome or square clear PVC windows, mesh window, glass window for glass wall |
|
|
(3) wooden flooring system: VIP cassette flooring, simple cassette flooring |
|
|
(4) doors: Double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual) |
|
|
(5) wall: Soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall |
|
|
(6) fixing methods: Ground anchors, weight plate, expandable bolts |
|
|
Rain gutters (inner roof beam rain gutter or rain gutter between two similar tents) |
|
|
(7) other optional items: Table, chair, lighting, AC, carpet, installation tools etc. |
|
Type |
Span(Width) |
Side height |
Ridge Height |
Main Profile(mm) |
Bay Distance |
|
MST-3 |
3m |
2.5m |
3m |
48*84*3 |
3m |
|
MST-6 |
6m |
2.5m |
3.5m |
48*84*3 |
3m |
|
MST-9 |
9m |
2.5m |
4.1m |
48*84*3 |
3m |
|
MST-10 |
10m |
2.5m |
4.3m |
48*84*3/48*100*3 |
3m |
|
MST-12 |
12m |
3m |
5m |
68*122*3 |
5m |
|
MST-15 |
15m |
3m |
5.4m |
108*150*3 |
5m |
|
MST-18 |
18m |
3m |
5.9m |
112*203*4 |
5m |
|
MST-20 |
20m |
4m |
7.2m |
112*203*4 |
5m |
|
MST-25 |
25m |
4m |
8m |
112*203*4 |
5m |
|
MST-30 |
30m |
4m |
8.8m |
113*259*5 |
5m |
|
MST-40 |
40m |
4m |
10.5m |
120*300*5 |
5m |
|
MST-50 |
50m |
4m |
12.2m |
128*350*5 |
5m |
Spacious Interior: Storage warehouse marquee tents offer a spacious interior that can be customized to suit workshop activities and storage needs. The absence of interior support columns or poles maximizes usable space, allowing for efficient organization and movement within the workshop.
Durable Construction: These tents are constructed with high-quality materials to withstand heavy use and outdoor conditions. The frame is typically made of sturdy materials such as galvanized steel or aluminum, providing structural stability and durability. The fabric cover is made of durable materials such as PVC or polyester, offering resistance to weather elements, UV rays, and abrasion.
Quick Assembly: Storage warehouse marquee tents are designed for quick and easy assembly, with pre-fabricated components that can be assembled on-site using basic tools and minimal labor. This allows for rapid deployment of workshop facilities, minimizing downtime and maximizing productivity.
Weather Resistance: The weather-resistant fabric cover and sturdy frame of storage warehouse marquee tents provide reliable protection for workshop activities and stored items against rain, wind, snow, sun exposure, and other outdoor elements. This ensures that workshop operations can continue uninterrupted regardless of weather conditions.
Customization Options: These tents often offer customization options to suit specific workshop requirements. This may include adding doors, windows, ventilation systems, lighting, insulation, or partition walls to optimize the space and functionality of the workshop.
1)Q: What is the life span of your tents?
A: Life span of the aluminium is 15-20 years, PVC fabric is 5-6 years. Good discount will be given you to get a new fabric from us after 5-6 years.
2)Q: How to assemble your tents?
A: We will provide the manual and video for you to study. If you need, we can send a technician to help you in your country.
3)Q: How to choose the size of the tent?
A: The size depends on how many people you want to stand, sit or have dinner in this tent. And the size also depends on the land space you will put up this tent.Normally,we advise 1-1.5sq.m/person.
4)Q: What is the warranty and safety of your tents?
A: Our tent is made by European standards and we own the CE/SGS quality management system certificate. Besides, we can design your tents with the emergency door and exit & panic lights to make sure the safety when have an emergency situation.
|
|
