| Brand Name: | Tendars |
| Model Number: | Big tent |
| MOQ: | 25 square meters |
| Price: | Reconsideration |
| Packaging Details: | 1, The aluminium frame structure packed into the bubble film 2, the pvc fabric roof cover and sidewalls are packed into the PVC fabric carry bag; 3, Hardware packed into the box. |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Item | Specification |
| Clear-span width | 3m - 50m |
| Eave height | 2.6m /3m/4m/5m/6m or customized |
| Ridge height | 4.3 - 8m or customized |
| Roof pitch | 20 |
| Longest component | 3.7-10.6m |
| Minimum tent length | Can be customized |
| Roof fixing | Not limited |
| Main profile | 84x48x3mm/ 122x68x3mm/ 166x88x3mm/ 203x112x4mm/ 204x112x4.5mm/ 256x120x5mm/ 300x125x5mm/ 350x126x6mm/ customized |
| Max.allowed wind speed | 100km/hour ,0.5kn/m³ or can be customized |
| Eave/Ridge connection | Hot-dip Galvanized steel insert |
| Materials | (1) Frame structure: Hard pressed extruded aluminium 6061 /T6(15HW) which can last 15 to 25 years. |
| (2) Fabric cover: High quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV | |
| resistant, tear resistant, self-cleaning ability, etc. | |
| (3) Connector: Strong hot-DIP galvanized steel | |
| Features | (1) Allowed temperature condition: -30 degree Celsius~+70 degree Celsius |
| (2) Wind load: Max. 80km/h (can be reinforced) | |
| (3) Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design) | |
| (4) Easy to be assembled and dismantled, movable. | |
| (5) No pole inside, 100% available interior space. | |
| Optional accessories | (1) Covers: Colourful cover, transparent cover, inflatable roof cover |
| (2) Windows: Dome or square clear PVC windows, mesh window, glass window for glass wall | |
| (3) Wooden flooring system: VIP cassette flooring, simple cassette flooring | |
| (4) Doors: Double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual) | |
| (5) Wall: Soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall | |
| (6) Fixing methods: Ground anchors, weight plate, expandable bolts | |
| Rain gutters (inner roof beam rain gutter or rain gutter between two similar tents) | |
| (7) Other optional items: Table, chair, lighting, AC, carpet, installation tools etc. |
| A-Frame Tent Type | |||||
| Width | Length | Bay distance | Side height | Ridge height | Max. wind load |
| 6m | Unlimited | 3m | 2.60m | 3.60m | 80km/h |
| 8m | Unlimited | 3m | 2.60m | 3.90m | 80km/h |
| 10m | Unlimited | 3m | 2.60m | 4.20m | 80km/h |
| 12m | Unlimited | 5m | 4.00m | 6.00m | 100km/h |
| 15m | Unlimited | 5m | 4.00m | 6.40m | 100km/h |
| 18m | Unlimited | 5m | 4.00m | 6.90m | 100km/h |
| 20m | Unlimited | 5m | 4.00m | 7.20m | 100km/h |
| 25m | Unlimited | 5m | 4.00m | 8.00m | 100km/h |
| 30m | Unlimited | 5m | 5.00m | 9.90m | 100km/h |
| 40m | Unlimited | 5m | 5.00m | 11.50m | 100km/h |
| 50m | Unlimited | 5m | 5.00m | 13.10m | 100km/h |
1) High security .
2) Heavy-duty and stable structure .
3) Elegant and magnificent appearance .
4) ISO9001, SGS,Coc, CE certificated .
5) No interior poles structure design ,to give 100% use of interior space .
6) Easy to assemble and demount .Convenient to transport and storage .
7) Wide range of applications; Widely used for outdoor party ,wedding ,celebration ,festival ,fashion show exhibition ,fair ,trade show ,business promotion ,product show ,car showrooms ,conference ,ceremony ,garden centres ,swimming pool cover ,cafe room ,temporary warehouse or workshop ,etc .
1)Q:Are you a factory or trading company?
A:We are a professional tent factory.So we can offer you a competitive price and a fast delivery time,can also control the quality well and supply constantly to insure the quantity.
2)Q:What is the life span of your tents?
A:Life span of the aluminium is 15-20 years,PVC fabric is 5-6 years. Good discount will be given you to get a new fabric from us after 5-6 years.
3)Q:How to assemble your tents?
A:We will provide the manual and video for you to study.If you need,we can send a technician to
help you in your country.
4)Q:How to choose the size of tent?
A:The size depends on how many people you want to stand,sit or have dinner in this tent.And the
size also depends on the land space you will put up this tent.Normally,we advise 1-1.5sq.m/person.
5)Q:What is the warranty and safety of your tents?
A:Our tent is made by European standards and we own the CE/SGS quality management system
certificate.Besides,we can design your tents with the emergency door and exit & panic lights to make sure the safety when have an emergency situation.
|
|
