| Brand Name: | Tendars |
| Model Number: | Big tent |
| MOQ: | 25 square meters |
| Price: | Reconsideration |
| Packaging Details: | 1, The aluminium frame structure packed into the bubble film 2, the pvc fabric roof cover and sidewalls are packed into the PVC fabric carry bag; 3, Hardware packed into the box. |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
1) Size: from 3 meters to 50meters
2) Eave height: standard from 2.5m, 3m, 4m to 5m upon span width (or special height per requested)
3) Length: Unlimited, extended by 3m or 5m each bay
|
Span(width) |
Side height |
Ridge height |
Longest part |
Main profile(mm) |
Bay distance |
|
3m |
2.5m |
3m |
2.7m |
36*71*2.5 |
3m |
|
6m |
2.5m |
3.5m |
3.2m |
48*84*3 |
3m |
|
8m |
2.5m |
3.9m |
4.3m |
48*84*3 |
3m |
|
9m |
2.5m |
4.1m |
4.8m |
48*84*3 |
3m |
|
10m |
2.5m |
4.3m |
5.3m |
48*84*3/48*100*3 |
3m |
|
12m |
3m |
5m |
6.3m |
68*122*3 |
5m |
|
15m |
3m |
5.4m |
7.9m |
108*150*3 |
5m |
|
18m |
3m |
5.9m |
9.5m |
112*203*4 |
5m |
|
20m |
4m |
7.2m |
10.6m |
112*203*4 |
5m |
|
25m |
4m |
8m |
10.6m |
112*203*4 |
5m |
|
30m |
4m |
8.8m |
10.6m |
113*259*5 |
5m |
|
35m |
4m |
9.6m |
10.6m |
120*300*5 |
5m |
|
40m |
4m |
10.5m |
11.1m |
120*300*5 |
5m |
|
45m |
4m |
11.3m |
11.1m |
128*350*5 |
5m |
|
50m |
4m |
12.2m |
11.1m |
128*350*5 |
5m |
|
The length can be extended by 3m such as 6m,12,18m,30m... or by 5m bay such as 15m,20m,30m,40m... Customized size or shape is available |
|||||
*Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more than 15 years.
*Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
*Connector: strong hot-dip galvanized steel
*Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
*Wind load: max.100km/h (can be reinforced)
*Snow load: 25kg/sqm (snow can't stay if use big degree roof pitch design)
*Easy to be assembled and dismantled, movable.
*No pole inside, 100% available interior space.
1. Are you tent factory?
Yes, we are professional tent manufacturer in Guangzhou of China, close to Shenzhen and HongKong.
We assure you our prices are based on factory.
2. What is the MOQ of the tent?
One Set.
3. What size tent and what types do i need?
Tent size depends on the number of people to accommodate or the area you want to cover. In our factory, you choice can be 3 meter to 50 meter on width.
For tent types, contact us with detailed requirements. We will send you our professional solution.
4. What is the production time for standard tent?
15-20 days after deposit confirmed.
5. What’s the lifespan of your clear span structure tent?
In the reasonable using, the lifespan of the aluminum alloy can last over 10 years and the PVC cover is more than 5 years.
6. Can your tent be relocated?
All our tent structures is designed into relocatable construction. For the seasonal and regional reason, you can dismantle, store or remove the tent to other location.
7. Can I extend the tent size or replace the related accessories in the future?
Sure. All of our tent structures and accessories are modular type. You can extend the tent length by adding some extra parts.
For accessories or replacements to renew the tents, we will offer a reasonable price for our regular clients.
8. What kind of warranty do you provide?
We provide an one year guarantee. During the warranty period, we shall replace the damaged part accordingly because of any damage due to quality problem.
|
|
