| Brand Name: | Tendars |
| Model Number: | Truss Frame |
| MOQ: | 25 square meters |
| Price: | Reconsideration |
| Packaging Details: | 1, The aluminium frame structure packed into the bubble film 2, the pvc fabric roof cover and sidewalls are packed into the PVC fabric carry bag; 3, Hardware packed into the box. |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
|
Size:400*400 |
|
|
Main tube: |
φ50*3mm |
|
Vice tube: |
φ30*2mm |
|
Brace tube: |
φ25*2mm Provide reinforced customization |
|
Load capacity: |
500KG |
|
Safe span: |
16M |
|
Material: |
GB6061-T6/6082-T6 |
|
Application: |
Indoor and outdoor background board, hanging spray painting cloth,decoration,stage,shapes, promotional activities |
Length: 2 meters (6.56 ft)
Outer diameter tube: 2 in (50 mm). Dimensions: 11.42 x 11.42 in (290 x 290 mm)
Diagonal bracing: 0.75 in (20 mm). Centerpoint load: 4,568 lbs (2,072 kg). Distributed load: 6,093 lbs (2,764 kg)
Wall thickness: 0.08 in (2 mm).Weight: 26.45 lbs (12 kg)
Approvals: TUV, SLV
1. Width__________M
2.Length________M
3. Height____M4.Need roof or not
Quality Material: the lighting truss is made of quality aluminum, with a sturdy structure, not easy to bend, corrosion resistant, and has good durability, especially for long term indoor and outdoor use, and is an essential addition to your stage setup
Suitable Truss Sizes for Versatile Uses: the square cross section dimension of the spigot truss is about 12 x 12 inches/ 290 x 290 mm, a total length of about 4.92 ft/ 1.5 m; The suitable dimensions provide a wide range of applications, from small shows to large theater productions
Excellent Load Capacity: the load capacity of a single DJ truss can reach up to 500 pounds and weighs 18.4 pounds; Thanks to the sturdy raw materials and the multi section reinforced design of the DJ aluminum trusses, even heavy-duty lamps and lighting fixtures can be hung safely
Convenient Lighting Truss System: the kit includes 2 lighting trusses and 8 connection couplers for quick and easy installation; The stage truss allows lighting designers the freedom to hang LED or Automated fixtures where ever they choose, increasing the versatility and adaptability of the stage setting
Classic Silver Finish: the square truss comes in a silver finish, ideal for a wide range of stage decors; This minimalist color blends with most stage gear, ensuring your stage setup looks coordinated, while also reflecting professionalism and elegance; Our box trusses are not only functions well but also enhance the overall visual appeal of the performance area.
Q1. What is the MOQ ?
200 sqm.
Q2:What is the material used for this stage and what are its features?
A:Aluminum Alloy 6061-T6；Used in large-scale performances, theatres, sports events, wedding venues, etc；Can do shaped stage.
Q3:Do you have a product installation guide?
A:YES, You can contact us by clicking here and we will provide you with a video to watch!
Q4:Is the colour of the panel optional?
A:YES,We have black; white; red; blue; yellow; customised.
Q5:How is product quality ensured?
A:Product testing load-bearing videos, quality inspection videos are available for viewing.
|
|
