Brand Name: | Tendars |
Model Number: | Big tent |
MOQ: | 25 square meters |
Price: | Reconsideration |
Packaging Details: | 1, The aluminium frame structure packed into the bubble film 2, the pvc fabric roof cover and sidewalls are packed into the PVC fabric carry bag; 3, Hardware packed into the box. |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
TENT Item NO.
|
Width
|
Bay
|
Side Height
|
Ridge height
|
Main Frame Profile
|
Wind Load
|
Snow Load
|
TDSS3
|
3m
|
3m
|
2.3m
|
2.85m
|
60x48mm
|
100km/h
|
0.3KN/M2
|
TDSS4
|
4m
|
3m
|
2.3m
|
3.05m
|
60x48mm
|
100km/h
|
0.3KN/M2
|
TDSS5
|
5m
|
3m
|
2.5m
|
3.45m
|
82x48mm
|
100km/h
|
0.3KN/M2
|
TDSS6
|
6m
|
3m
|
2.5m
|
3.65m
|
82x48mm
|
100km/h
|
0.3KN/M2
|
TDSS8
|
8m
|
3m
|
2.5m
|
4.05m
|
82x48mm
|
100km/h
|
0.3KN/M2
|
TDSS9
|
9m
|
3m
|
2.5m
|
4.2m
|
100x48mm
|
100km/h
|
0.3KN/M2
|
TDSS10
|
10m
|
5m
|
3m
|
4.9m
|
122x68mm
|
100km/h
|
0.3KN/M2
|
TDSS12
|
12m
|
5m
|
3m
|
5.85m
|
122x68mm
|
100km/h
|
0.3KN/M2
|
TDSS15
|
15m
|
5m
|
3m
|
5.35m
|
166x88mm
|
100km/h
|
0.3KN/M2
|
TDSS18
|
18m
|
5m
|
3m
|
5.8m
|
166x88mm
|
100km/h
|
0.3KN/M2
|
TDSS20
|
20m
|
5m
|
4m
|
7.2m
|
203x112mm
|
100km/h
|
0.3KN/M2
|
TDSS22
|
22m
|
5m
|
4m
|
7.45m
|
203x112mm
|
100km/h
|
0.3KN/M2
|
TDSS25
|
25m
|
5m
|
4m
|
7.95m
|
203x112mm
|
100km/h
|
0.3KN/M2
|
TDSS30
|
30m
|
5m
|
4m
|
8.7m
|
250x120mm
|
100km/h
|
0.3KN/M2
|
TDSS40
|
40m
|
5m
|
4m
|
10.2m
|
340x170mm
|
100km/h
|
0.3KN/M2
|
TDSS50
|
50m
|
5m
|
4m
|
11.9m
|
340x170mm
|
100km/h
|
0.3KN/M2
|
TDSS60
|
60m
|
5m
|
4m
|
13.5m
|
340x170mm
|
100km/h
|
0.3KN/M2
|
First of all, some analysis of the tent frame and materials:
1, the main frame of the tent is generally based on aluminum, beautiful, convenient and practical, and the parts connecting them are a
Some hot dip galvanized iron parts mainly
2. Generally, the surface of aluminum profiles will be treated with peroxide or fluorocarbon paint
And for tarpaulin is also very particular, there are mainly the following:
1, First of all, the fabric used on the top of the frame and the parts around it is processed by a double layer, and the fabric
PVC is generally made of polyester filament
2, the role of tarpaulin is also many, waterproof, fire, anti-ultraviolet and other functions
3, of course, these also have the corresponding certificate confirmed, and the specifications of the tent in addition to special customization is also unified
Several specifications.
7.1 The temporary construction of the house shall be prepared to use the manual and strictly in accordance with the provisions of the use, shall not change the use of work at will
I can.
7.2 Regular inspection and maintenance shall be carried out according to the instructions during use.
7.3 The room in contact with the fire source must be fireproof treatment, and the upper floor of the room shall not live or work.
7.4 The tent shall be inspected periodically, and the period between thorough inspections shall not exceed 3 years. Inspect
This should be done before tent installation. In special cases, the tent can be dismantled. The inspection should include the following
Content:
Calibration assembly;
To inspect structures, especially those that have been altered, repaired or replaced;
Check for damage and corrosion.
