| Brand Name: | Tendars |
| Model Number: | Big tent |
| MOQ: | 25 square meters |
| Price: | Reconsideration |
| Packaging Details: | 1, The aluminium frame structure packed into the bubble film 2, the pvc fabric roof cover and sidewalls are packed into the PVC fabric carry bag; 3, Hardware packed into the box. |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Main Frame | Span Width: From 3m to 60m |
| Structure | Aluminum size: 100mm x 48mm x 2.7mm, 150mm x 120mm x 3mm, 203mm x 112mm x 4.5mm,250mm x 120mm x 4.0mm,300mm x 120mm x 5.0mm |
| Material: Hard Pressed Extruded Aluminum Alloy 6061-T6/6082-T6 | |
| Roof material | Density: 650g/㎡ - 850g/㎡ |
| Material: Both sides lacquered PVC coated fabric | |
| Features: UV resistant, waterproof, fire retardant B1 | |
| Sidewall | PVC White or Clear Wall, Glass Wall, ABS Wall |
| Wind Load | 20km/h |
| Snow Load | 10cm Thick Floating Snow |
| Temperature Index | -30 Degree Celsius to +70 Degree Celsius |
| Life Time | Frame more than 15 years. PVC fabric 5-10 years. |
| Certification | SGS, ISO 9001:2015, IAF, NAC |
| Optional Accessories | Color of PVC Roof and Sidewall, Clear PVC Window Sidewalls, Glass Windows, Glass Door Units, Flooring System, Fixed Way, Rain Gutter between two tents, etc. |
| Quality control | 1. Higher factory standard for all material; | |||
| 2. Incoming material 100% batch inspection; | ||||
| 3. Pipelining; | ||||
| 4. On site process inspection; | ||||
| 5. Finshed inspection and pressure test; | ||||
| 6. Loading inspection; | ||||
| Application | Commercial operation, Farm, ski resort, Swim training centre, Commercial advertisement | |||
| Production process | Charting - Printing - Cutting - Stitching - Pasting - Packaging | |||
| Parts | Details |
| Cover | PVC cover/Clear PVC cover |
| Walls | PVC walls/ABS hard walls/Tempered glass walls |
| Windows | Clear PVC windows/Mesh windows/Glass windows |
| Doors | Glass door/ Aluminium door/Rolling shutter |
| Floor | Stage/Cassette floor/Wooden floor |
| Rain Gutters | Inner/External roof beam rain gutter |
| Decoration | Ceiling lining/Curtain |
| Fixing tools | Ground anchors/Weight plate/Expandable bolts/Drilling steel |
| Others | Air conditioner/Table/ chair/ Lamp/Carpet |
|
